Weidmuller

Contact type: Socket (Female) | Modular spacing contacts: 5.08 mm | Number of poles: 24

Type of end plate: yes | Type of partition: no | Colour: Blue

Mounting method: Other | Type of electrical connection 1: Other | Width: 4.15 mm

Type of housing: Housing extension | Height: 38 mm | Width: 120 mm

Type of housing: Plug case | Height: 72 mm | Width: 43 mm

Number of clamp positions per level: 6 | Rated current In: 125 A | Type of electrical connection 1: Screw connection

Type of plug-in contact, field sided: Female (bus) | Cable length: 10 m | Type of electrical connection, field-sided: M12

Type of connection: Printed circuit board to cable | Contact type: Socket (Female) | Number of poles: 12

Type of connection: Printed circuit board to cable | Contact type: Pin | Number of poles: 3

Type of fuse insert: G-fuse 5x20 mm | Connectable conductor cross section fine-strand without cable end sleeve: 0.5...10 mm² | Type of fuse holder: Swivelling

Connectable conductor cross section fine-strand without cable end sleeve: 1...1.5 mm² | Rated voltage: 250 V | Strip length: 6 mm

Length: 30 mm | Material: Plastic | Cable diameter: 0.25...2.5 mm

Type: Medium-walled | Core diameter: 2.5...10 mm | Material: Plastic

Bolt dimension metric (M..): 5 | Nominal cross section: 10 mm² | Connecting angle: 180° (horizontal)

Type of coding element: Other

Height: 306 mm | Width: 306 mm | Depth: 150 mm

Modular spacing connections: 3.5 mm | Rated current In: 16 A | Number of electrical connections: 4

Sleeve length: 26 mm | Nominal cross section: 6 mm² | Construction type: Standard

Self-adhesive: no | Text: Unprinted | Colour: White

Type: Medium-walled | Model: Roller shape | Material: Plastic
