Weidmuller

Type of plug-in contact, field sided: Male (plug) | Type of electrical connection, field-sided: M12 | Number of poles: 5

For cable outer diameter: 6...8 mm | Type of electric plug connection: Screw connection | Contact type: Pin

Type of connection: Printed circuit board to cable | Contact type: Pin | Number of poles: 18

Type of branches for sensor-/actuator cables: Other | Number of poles sensor/actuator slots: 5 | Number of sensor-/actuator-slots: 8

Nominal voltage DC: 16...16 V | Max. continuous voltage AC: 13.2 V | Nominal voltage AC: 12...12 V

Sleeve length: 25 mm | Nominal cross section: 1 mm² | Construction type: Twin cable end sleeve

Modular spacing connections: 5.08 mm | Rated current In: 24 A | Number of electrical connections: 8

Contact type: Pin | Modular spacing contacts: 5.08 mm | Number of poles: 6

Type of electric plug connection: Plug-in connection | Rated control supply voltage Us at DC: 24...24 V | Number of contacts as change-over contact: 1

Type of accessory/spare part: Screw

Type of connection: Printed circuit board to cable | Contact type: Pin | Number of poles: 4

Height: 43 mm | Width: 102 mm | Depth: 62 mm

Height: 112.5 mm | Width: 6.1 mm | Depth: 114.3 mm

For cable outer diameter: 6...8 mm | Type of electric plug connection: Screw connection | Contact type: Socket (Female)

Height: 260 mm | Width: 260 mm | Depth: 200 mm

Type of connection: Printed circuit board to cable | Contact type: Pin | Number of poles: 16

Transparent: yes | Length: 1000 mm | Colour: Other

Type of branches for sensor-/actuator cables: Other | Number of poles sensor/actuator slots: 5 | Number of sensor-/actuator-slots: 4

Type of connection: Printed circuit board to cable | Contact type: Socket (Female) | Number of poles: 4

Pole fastening: no | Material: Aluminium | Floor standing wall model: no
