Allen-Bradley - 24VDc 4 Channel HD Analog Current In - 1734-IE4C
/ each
£386.95
Delivery
Essential specifications
Number of analogue inputs - 4
Number of analogue outputs - 0
Input, current - yes
Input, voltage - yes
Output, current - no
Packaging
1 each
GTIN
10612598345417
Supplier Ref
1734-IE4C
Manufacturer Ref
1734-IE4C
Commercial Reference
1734-IE4C
Number of analogue inputs:
4
Number of analogue outputs:
0
Input, current:
yes
Input, voltage:
yes
Output, current:
no
Output, voltage:
no
Supporting protocol for TCP/IP:
yes
Supporting protocol for MODBUS:
no
Supporting protocol for Data-Highway:
no
Supporting protocol for DeviceNet:
no
Supporting protocol for EtherNet/IP:
no
Supporting protocol for DeviceNet Safety:
no
Supporting protocol for other bus systems:
no
IO link master:
no
Type of electric plug connection:
Plug-in connection
Rail mounting possible:
yes
Wall mounting/direct mounting:
no
Front installation possible:
yes
Rack-assembly possible:
no
Width:
12 mm
Height:
56 mm
Depth:
75.5 mm
POINT I/O. Analogue input module. Current. 4 x 0-20mA, 4-20mA. 16 bit resolution. TB/TBS terminal base
- Modular design lets you independently select the I/O, termination style, and network interface.
- Modules slide together for easy install and uninstall for easier maintenance
- Removable wiring system saves time and money during installation and troubleshooting.
- Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply.
- Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation.
- Mount horizontally or vertically, with no de-rating required.
- Auto Device Replacement (ADR) reduces downtime.
- Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems.
- Available with conformal coating.
Allen-Bradley
