Allen-Bradley - Allen Bradley Switched Mode Compact Power supply 24V DC 7.5A - 1606-XLP90B
/ each
£283.40
Delivery
Essential specifications
Voltage type of supply voltage - AC/DC
1st secondary output voltage - 12...15 V
Max. output current 1 - 7.5 A
Nominal value output voltage 1 - 12 V
Nominal value output current 1 - 6 A
Packaging
1 each
GTIN
10781180454360
Supplier Ref
1606-XLP90B
Manufacturer Ref
1606-XLP90B
Commercial Reference
1606-XLP90B
Voltage type of supply voltage:
AC/DC
1st secondary output voltage:
12...15 V
Max. output current 1:
7.5 A
Nominal value output voltage 1:
12 V
Nominal value output current 1:
6 A
Rated supply voltage at AC 50 Hz:
100...120 V
Rated supply voltage at DC:
220...375 V
Power output:
90 W
Type of electric plug connection:
Screw-/spring clamp connection
Rail mounting possible:
yes
Width:
73 mm
Height:
75 mm
Depth:
103 mm
IP-rating:
IP20
Allen Bradley Switched Mode Compact Power supply 24V DC 100-240V AC Input 7.5A DIN Rail Mounted. Our Bulletin 1606-XLP Compact Switched Mode Power Supplies are an excellent choice when you need to save space. These devices are equipped with many of the same features and certifications as the XL devices and support low-power applications.
- Includes rated outputs between 15…100 W (0.6…4.2 A at 24V DC)
- Offers multiple output voltages
- Offers multiple single and three-phase inputs for global applications
- Provides a smaller, cost-effective solution for low power applications
- Provides redundancy modules for managing dual power supplies for back-up power
Allen-Bradley
Explore more products in this series
