Allen-Bradley - Power Feed 40A Ax,24V DC - 1694-PFA1244
£28.81
/ each
£28.81
1
Delivery
Number of available items for delivery:24
Essential specifications
Adjustable current range - 40...40 A
Rated control supply voltage Us at DC - 24...24 V
Connection type main current circuit - Spring clamp connection
Voltage type for actuating - DC
Packaging
1 each
GTIN
00191326940702
Supplier Ref
1694-PFA1244
Manufacturer Ref
1694-PFA1244
Commercial Reference
1694-PFA1244
Adjustable current range:
40...40 A
Rated control supply voltage Us at DC:
24...24 V
Connection type main current circuit:
Spring clamp connection
Voltage type for actuating:
DC
Electronic Circuit Protection, Power Feed, Left Mount, Supply Voltage 24V DC, Imax 40A, with AUX Contact.
- Combination of supply modules, circuit protection and power distribution
- Selective load protection by means of electronic trip curve
- No accessories required for connecting the components
- Width per channel only 12.5 mm (1-channel) or 6.25mm (2-channel)
- Integral fail-safe element, adjusted to current rating
- Switching capacitive loads up to 20,000 µF (at IN > 6A)
- Manual ON/OFF/reset momentary switch
- Clear status indication by means of LED and auxiliary contact (1694-PF supply module)
- Connection via push-in terminals
- 1694-PMx available in Class 2 version with nominal currents: 1A, 2A, 3A, 4A
Allen-Bradley
