Allen-Bradley - PowerFlex 753 AC Drive - 20F11FC072JA0NNNNN
/ each
£6,855.90
Delivery
Essential specifications
Mains voltage - 380...480 V
Nominal output current I2N - 72 A
Max. output at quadratic load at rated output voltage - 37 kW
IP-rating - IP20
Mains frequency - 50/60 Hz
Packaging
1 each
GTIN
00884951163928
Supplier Ref
20F11FC072JA0NNNNN
Manufacturer Ref
20F11FC072JA0NNNNN
Commercial Reference
20F11FC072JA0NNNNN
Mains voltage:
380...480 V
Nominal output current I2N:
72 A
Max. output at quadratic load at rated output voltage:
37 kW
IP-rating:
IP20
Mains frequency:
50/60 Hz
Number of phases input:
3
Number of phases output:
3
Max. output at linear load at rated output voltage:
30 kW
Application in domestic- and commercial area permitted:
yes
Supporting protocol for Data-Highway:
no
Number of HW-interfaces industrial Ethernet:
1
Height:
535 mm
Width:
292 mm
Depth:
127.4 mm
PowerFlex 753 AC Drive, with Embedded I/O, Air Cooled, AC Input with DC Terminals, Flange Type, 72 Amps, 37kW ND, 30kW HD, 400 VAC, 3 PH, Frame 4, Filtered, CM Jumper Installed, DB Transistor, Blank (No HIM)
