Bussmann - BUSSMAN FUSES - FNQ-R-3
£43.77
/ each
£43.77
1
Delivery
Number of available items for delivery:0
Essential specifications
Size - 10x38 mm
Rated current - 0.3 A
Voltage type - AC
Release characteristic - CC
Utilization category - Other
Packaging
1 each
GTIN
Supplier Ref
FNQ-R-3
Manufacturer Ref
FNQ-R-3
Commercial Reference
FNQ-R-3
Size:
10x38 mm
Rated current:
0.3 A
Voltage type:
AC
Release characteristic:
CC
Utilization category:
Other
Rated operation frequency:
45...62 Hz
3a 600v Class Cc Cc-tron Time Delay Fuse
- Provides 10X better current limitation to help prevent equipment damage caused by shortcircuit events.
- 200kA interrupting rating complies with NEC® Section 110.9 for today’s large capacity systems.
- Fast-acting fuse helps prevent equipment damage caused by short-circuit events.
- Rejection type fuse fits both standard and rejection-style holders.
- The Class CC FNQ-R Limitron fuse meets the needs of control circuit transformer protection.
- FNQ-R fuses can be sized according to NEC® and UL requirements and still allow the high inrush currents, with significantly more timedelay than the UL minimum value of 12 seconds at 200% for Class CC fuses.
- Ideal for critical industrial or commercial applications that have specific current limitation requirements
Bussmann
