Guardmaster - BBM,1NO 2NC Circuits,6-Pin AC M12 QD - 440P-CRPB12R6

Number of contacts as normally closed contact:

2

Number of contacts as normally open contact:

1

Type of control element:

Plunger

Width sensor:

31 mm

Height of sensor:

31 mm

Length of sensor:

90 mm

Rated operation current Ie at AC-15, 125 V:

6 A

Rated operation current Ie at AC-15, 230 V:

3 A

Rated operation current Ie at DC-13, 125 V:

2.2 A

Rated operation current Ie at DC-13, 230 V:

1.1 A

Number of safety auxiliary contacts:

2

Material housing:

Plastic

Suitable for safety functions:

yes

Ambient temperature during operating:

-25...80 °C

IP-rating:

IP66

Degree of protection (NEMA):

1
