MTL - 1-ch smart 4-20mA output + LFD - MTL4546Y

Number of channels:

1

IP-rating:

IP20

Rated supply voltage at DC:

24...24 V

Number of input ranges 4 mA ... 20 mA:

1

Number of output ranges 0 V ... 10 V:

0

Number of output ranges 0 mA ... 20 mA:

0

Number of output ranges 4 mA ... 20 mA:

1

Galvanic separation between input and output:

yes

Height:

121.8 mm

Width:

104.8 mm

Depth:

15.8 mm

Operation temperature:

-20...60 °C

Type of electric plug connection:

Screw connection

Mounting method:

Other
