MTL - 1 CH SMART TRANSMITTER REPEATER 2 PORT - MTL4541B
/ each
£361.00
Delivery
Essential specifications
Number of channels - 1
IP-rating - IP20
Rated supply voltage at DC - 24...24 V
Number of output ranges 0 V ... 10 V - 0
Number of output ranges 0 mA ... 20 mA - 0
Packaging
1 each
GTIN
Supplier Ref
MTL4541B
Manufacturer Ref
MTL4541B
Commercial Reference
MTL4541B
Number of channels:
1
IP-rating:
IP20
Rated supply voltage at DC:
24...24 V
Number of output ranges 0 V ... 10 V:
0
Number of output ranges 0 mA ... 20 mA:
0
Number of output ranges 4 mA ... 20 mA:
2
Galvanic separation between input and output:
yes
Height:
121.8 mm
Width:
104.8 mm
Depth:
15.8 mm
Operation temperature:
-20...60 °C
Type of electric plug connection:
Screw connection
Mounting method:
Other
MTL4500. Analogue input isolator. Repeater Power supply. 1 channel. Hazardous 4-20mA 2/3 wire. Safety 4-20mA. HART. Supply 20...35V DC. Adapted for MTL 4041B substitution on legacy backplanes
- Rapid install-and-release mechanism
- Highest packing density on the market
- Single and multi-channel I/O modules
- 3-port isolation with low power dissipation
- Compatible with MTL4000
