MTL - 4-ch digital input - MTL5510
£424.00
/ each
£424.00
1
Delivery
Number of available items for delivery:2
Essential specifications
Type of power supply - Active
Rated supply voltage at DC - 20...35 V
Number of inputs, according to NAMUR - 4
Number of channels - 4
Switching frequency - 500 Hz
Packaging
1 each
GTIN
Supplier Ref
MTL5510
Manufacturer Ref
MTL5510
Commercial Reference
MTL5510
Type of power supply:
Active
Rated supply voltage at DC:
20...35 V
Number of inputs, according to NAMUR:
4
Number of channels:
4
Switching frequency:
500 Hz
Operation temperature:
-20...60 °C
Mounting method:
Snap mounting support rail
IP-rating:
IP20
MTL5500. Digital input isolator. Switch/proximity detector. 4 channel. 4 x proximity switch. 4 x solid state. LFD. Supply 20...35V DC
- Compact modular design with DIN rail mounting
- High packing density
- Single and multi-channel I/O modules
- 3-port isolation with low power dissipation
- Compatible with MTL5000
MTL
