Phoenix Contact - HCC 4-M PLUG - 1600014

Model:

Pin insert

Connectable conductor cross section fine-strand without cable end sleeve:

0.2...4 mm²

Rated current In:

25 A

Type of electric plug connection:

Screw connection

Number of poles:

10

Connectable conductor cross section:

0.2...4 mm²

Connectable conductor cross section fine-strand with cable end sleeve:

0.25...4 mm²

Connectable conductor cross section solid-core:

0.2...4 mm²

Connectable conductor cross section multi-wired:

0.2...4 mm²

Rated voltage:

25 V

Total number of poles (without ground contact):

10

Width:

7.62 mm

Stackable:

no
