Phoenix Contact - MKKDS 1/ 6-3,81 - 1708068

Number of electrical connections:

6

Modular spacing connections:

3.81 mm

Rated current In:

8 A

Connection type conductor:

Screw connection

Housing colour:

Green

Height:

16.2 mm

Number of levels:

2

Angle PCB/conductor connection:

0°/180° (horizontal)

Rated voltage:

200 V

Rated surge voltage:

2.5 kV

Over voltage category:

III

Pollution degree:

2

Connectable conductor cross section solid-core:

0.14...1.5 mm²

Connectable conductor cross section fine-strand with cable end sleeve:

0.25...0.5 mm²

Connectable conductor cross section fine-strand without cable end sleeve:

0.14...1 mm²

Connectable conductor cross section multi-wired:

0.14...1 mm²

Connection type PCB:

Soldering connection

Material connection surface:

Tin

Length pin:

3.5 mm

Material insulation body:

Thermoplastic

Type of PCB fastening:

Connecting contact

Type of fastening:

Solder
