Puls - 20A 48-54Vdc 200-240Vac - QS40.484

Voltage type of supply voltage:

AC/DC

Max. output current 1:

20 A

Secondary voltage adjustable:

yes

Nominal value output voltage 1:

48 V

Short-circuit-proof:

yes

Rated supply voltage at AC 50 Hz:

200...240 V

Rated supply voltage at DC:

48...54 V

Output voltage stabilized:

yes

Power output:

960 W

Type of electric plug connection:

Spring clamp connection

Rail mounting possible:

yes

Suitable for wall mounting:

no

Suitable for DIN installation panels:

yes

Width:

125 mm

Height:

124 mm

Depth:

127 mm

IP-rating:

IP20
