Red Lion - CUB4 CURRENT METER, GREEN - CUB4I010
£172.00
/ each
£172.00
1
Delivery
Number of available items for delivery:0
Essential specifications
Measuring range - 2...0.02 A
Transformer connection - no
Voltage type - DC
Measurement system - Digital
Nominal end value of the scale - 0.02 A
Packaging
1 each
GTIN
Supplier Ref
CUB4I010
Manufacturer Ref
CUB4I010
Commercial Reference
CUB4I010
Measuring range:
2...0.02 A
Transformer connection:
no
Voltage type:
DC
Measurement system:
Digital
Nominal end value of the scale:
0.02 A
Power loss:
0.112 W
Over current scale:
no
Calibrated:
no
Model:
Front mounting
Suitable for DIN installation panels:
no
Width:
75 mm
Height:
39 mm
Stay-set indicator:
no
Scales lighting:
no
CUB4 DC Current Meter, Yellow/Green Negative Image Backlighting
- LCD, positive reflective or negative transmissive with yellow/green or red backlighting
- Four selectable d.c. ranges
- 0 to 199.9 mv, 1.999 v, 19.99 v, 199.9 v (cub4v)
- 0 to 199.9 μa, 1.999 ma, 19.99 ma, 199.9 ma (cub4i)
- 0.6 inch (15.2 mm) high lcd digits
- Built-in scaling provided
- Auto zeroing circuit
- Selectable decimal points
- Wire connections made via screw clamp type terminals
- fiFs din standard cut-out 2.68" (68 mm) x 1.30" (33 mm)
- Nema 4x/ip65 sealed front panel bezel
- 9 to 28 vdc powered
Red Lion
