Red Lion - Dual Count + Rate Indicatr w/Reflctve Ds - CUB5R000
£138.00
/ each
£138.00
1
Delivery
Number of available items for delivery:0
Essential specifications
Input voltage at DC - 10...28 V
Model - Surface mounting
Number of digits - 8
Voltage type - DC
Suitable for DIN installation panels - no
Packaging
1 each
GTIN
Supplier Ref
CUB5R000
Manufacturer Ref
CUB5R000
Commercial Reference
CUB5R000
Input voltage at DC:
10...28 V
Model:
Surface mounting
Number of digits:
8
Voltage type:
DC
Suitable for DIN installation panels:
no
Width:
75 mm
Height:
39 mm
Measuring mechanism:
Digital
With reset function:
yes
CUB5 Dual Counter & Rate Indicator with Reflective Display
- LCD, REFLECTIVE OR GREEN/RED LED BACKLIGHTING
- 0.46" (11.7 mm) HIGH DIGITS
- OPTIONAL SETPOINT OUTPUT CARD
- OPTIONAL SERIAL COMMUNICATIONS CARD (RS232 or RS485)
- OPTIONAL USB PROGRAMMING CARD
- OPERATES FROM 9 TO 28 VDC POWER SOURCE
- PROGRAMMABLE SCALING FOR COUNT AND RATE
- BI-DIRECTIONAL COUNTING, UP/DOWN CONTROL
- QUADRATURE SENSING (UP TO 4 TIMES RESOLUTION)
- BUILT-IN BATCH COUNTING CAPABILITY
- DISPLAY COLOR CHANGE CAPABILITY AT SETPOINT OUTPUT
- NEMA 4X/IP65 SEALED FRONT BEZEL
