Allen-Bradley - 4-Channel RTD Resistance Input Module for MicroLogix 1200 PLC - 1762-IR4
£700.65
/ each
£700.65
1
Delivery
Number of available items for delivery:1
Essential specifications
Number of analogue inputs - 4
Number of analogue outputs - 0
Input, current - no
Input, voltage - no
Input, resistor - no
Packaging
1 each
GTIN
10611320861676
Supplier Ref
1762-IR4
Manufacturer Ref
1762-IR4
Commercial Reference
1762-IR4
Number of analogue inputs:
4
Number of analogue outputs:
0
Input, current:
no
Input, voltage:
no
Input, resistor:
no
Input, resistance thermometer:
yes
Input, thermocouple:
no
Resolution of the analogue inputs:
16 Bit
Output, current:
no
Output, voltage:
no
Type of electric plug connection:
Screw connection
Explosion safety category for gas:
None
Explosion safety category for dust:
None
Width:
40.4 mm
Height:
90 mm
Depth:
87 mm
MicroLogix 1200. Channel, RTD/Resistance Module
- Contains isolated RS-232/RS-485 combo port for serial and networked communication
- Provides four latching or pulse-catch inputs and four interrupt inputs
- Includes built-in independent 20 kHz high-speed counter
- Offers Programmable Limit Switch function
- Includes two built-in ¾-turn trim potentiometers with a digital output range of 0...250
- Provides program data security
- Supports floating point data files
- Expands up to 136 I/O points
- Compatible with 1762 MicroLogix Expansion I/O modules (up to six modules per controller)
- Provides additional programming/HMI port for connectivity to a DF1 full-duplex compatible device (only on MicroLogix™ 1200R controllers)
