Allen-Bradley - Allen Bradley Performance Power Supply 12V DC 15A - 1606-XLS180B
/ each
£486.26
Delivery
Essential specifications
Voltage type of supply voltage - AC/DC
1st secondary output voltage - 12...15 V
Max. output current 1 - 15 A
Nominal value output voltage 1 - 12 V
Nominal value output current 1 - 15 A
Packaging
1 each
GTIN
10662074643933
Supplier Ref
1606-XLS180B
Manufacturer Ref
1606-XLS180B
Commercial Reference
1606-XLS180B
Voltage type of supply voltage:
AC/DC
1st secondary output voltage:
12...15 V
Max. output current 1:
15 A
Nominal value output voltage 1:
12 V
Nominal value output current 1:
15 A
Rated supply voltage at AC 50 Hz:
100...240 V
Rated supply voltage at DC:
110...150 V
Power output:
180 W
Type of electric plug connection:
Spring clamp connection
Rail mounting possible:
yes
Width:
60 mm
Height:
124 mm
Depth:
117 mm
IP-rating:
IP20
Allen Bradley Performance Power Supply 12V DC 100-240V AC Input 15A DIN Rail Mounted. Our Bulletin 1606-XLS Performance Switched Mode Power Supplies use a technology that significantly reduces unit size yet delivers a 150% power boost. These power supplies offer DC output choices of 5, 12, 15, 24, and 48V in 80...960 W sizes.
- Includes rated outputs between 80…960 W (3.3...40 A at 24V DC)
- Features 150% power boost to handles start-up loads
- Includes multiple single and three-phase inputs for global applications
- Offers small size for panel space savings
- Provides buffer modules for a short boost function, buffering load currents during typical main faults, switching events, or load peaks
- Provides redundancy modules for managing dual power supplies for back-up power
