Allen-Bradley - Allen Bradley Switched Mode Performance Power Supply 24V DC 8A - 1606-XLSDNET8
/ each
£545.02
Delivery
Essential specifications
Voltage type of supply voltage - AC/DC
1st secondary output voltage - 24...24 V
Max. output current 1 - 8 A
Nominal value output voltage 1 - 24 V
Nominal value output current 1 - 8 A
Packaging
1 each
GTIN
10781180833868
Supplier Ref
1606-XLSDNET8
Manufacturer Ref
1606-XLSDNET8
Commercial Reference
1606-XLSDNET8
Voltage type of supply voltage:
AC/DC
1st secondary output voltage:
24...24 V
Max. output current 1:
8 A
Nominal value output voltage 1:
24 V
Nominal value output current 1:
8 A
Rated supply voltage at AC 50 Hz:
100...240 V
Rated supply voltage at DC:
110...300 V
Power output:
192 W
Type of electric plug connection:
Spring clamp connection
Rail mounting possible:
yes
Width:
60 mm
Height:
124 mm
Depth:
117 mm
IP-rating:
IP20
Allen Bradley Switched Mode Performance Power Supply 24V DC 100-240V AC Input 8A DIN Rail Mounted. Our Bulletin 1606-XLS Performance Switched Mode Power Supplies use a technology that significantly reduces unit size yet delivers a 150% power boost. These power supplies offer DC output choices of 5, 12, 15, 24, and 48V in 80...960 W sizes.
- Industry-Leading Efficciency
- Intelligent circuit design with long-life electrolytic capacitors
- Generates minimal heat
- Allows up to 50% additional power reserve without reducing output voltage, while minimizing ripple and noise
- Wide Power Range and Feature Set
- Multiple single- and three-phase inputs available for global applications
- Redundancy modules provide a means for managing dual power supplies for back-up power
- Multiple output voltages available
- Compact Size
- Saves space on plant floor
- Expands plant flexibility
- Approvals
- CE marked
- cULus and cURus listed
