Allen-Bradley - Compact GuardLogix5380 Safety Controller - 5069-L340ERMS2
/ each
£8,240.17
Delivery
Essential specifications
Model - Compact
Number of relay outputs - 0
Number of HW-interfaces industrial Ethernet - 2
Number of HW-interfaces USB - 1
Supporting protocol for TCP/IP - yes
Packaging
1 each
GTIN
00889508434414
Supplier Ref
5069-L340ERMS2
Manufacturer Ref
5069-L340ERMS2
Commercial Reference
5069-L340ERMS2
Model:
Compact
Number of relay outputs:
0
Number of HW-interfaces industrial Ethernet:
2
Number of HW-interfaces USB:
1
Supporting protocol for TCP/IP:
yes
Supporting protocol for EtherNet/IP:
yes
Display:
yes
Memory size:
4096 kByte
Front installation possible:
yes
SIL according to IEC 61508:
2
Performance level acc. to EN ISO 13849-1:
Level d
Width:
98.1 mm
Height:
143.97 mm
Depth:
136.81 mm
Compact GuardLogix5380 Safety Controller, SIL2/PLd, 4.0MB Standard & 2.0MB Safety Memory, 90 nodes, 31 I/Os, 20 axis
- CompactLogix 5380 controllers are ideal for applications requiring high-performance communications, I/O, and motion control for up to 32 axes.
- Ideal for small to mid-size applications that require low axis motion and I/O point counts
- Enable high-speed I/O, motion control, and Device Level Ring/Linear Topologies
- Offer a 1 gigabit (Gb) embedded Ethernet port that enables high-speed communications, I/O, and motion control
- Include dual configurable ports that supports Dual IP address
- Provide enhanced diagnostics and troubleshooting
- Offer controller functions optimized for maximum system performance
- Offer enhanced security features which include digitally-signed controller firmware, controller-based change detection, and logging and role-based access control to routines and Add-On Instructions
- Support up to 31 Bulletin 5069 Compact I/O modules
- Offer Integrated Motion on EtherNet/IP up to 32 axes
- Offer a wide range of memory options from 0.6...10 MB
Allen-Bradley
