Allen-Bradley - GROUND SPRING CLAMP TERMINAL BLOCK TRIP - 1492-LG6T
/ 50 each
£6.66
Delivery
Essential specifications
Connectable conductor cross section fine-strand without cable end sleeve - 6...6 mm²
Type of electrical connection 1 - Spring clamp connection
Number of levels - 1
Number of clamp positions per level - 2
Connectable conductor cross section solid-core - 6...6 mm²
Packaging
1 each
GTIN
10662073056451
Supplier Ref
1492-LG6T
Manufacturer Ref
1492-LG6T
Commercial Reference
1492-LG6T
Connectable conductor cross section fine-strand without cable end sleeve:
6...6 mm²
Type of electrical connection 1:
Spring clamp connection
Number of levels:
1
Number of clamp positions per level:
2
Connectable conductor cross section solid-core:
6...6 mm²
Type of electrical connection 2:
Spring clamp connection
Mounting method:
DIN rail (top hat rail) 35 mm
Material insulation body:
Thermoplastic
Operation temperature:
-50...120 °C
Width:
8.1 mm
Depth:
90 mm
End plate required:
yes
Colour:
Green/yellow
Spring Clamp Terminal Block, One-Circuit Feed-Through Ground Block, 6 mm (# 22 AWG - # 10 AWG), 4 mm for H4 block, 2 Connection points on one side, Green / Yellow Stripe (Standard),
- Tin-plated terminals and stainless steel spring clamps for resistance to corrosion and vibration
- Spring clamp design to minimize stress relaxation and maintain contact force, even under vibration
- Top wire entry for ease of installation
- Circuit testing with standard 2 mm diameter test probe or stackable test plugs on most spring-clamp blocks
- Insulation stops to ensure electrical connection when using smaller gauge wires
- Markers that are visible after terminal blocks are wired
- Multiple marking options
- Common profiles to minimize stocking of accessories
- Self-extinguishing, polymide 6.6 housing materials with a flammability rating UL 94-V0 (1492-R terminal blocks have a UL 94-V2
- flammability rating)
- Screwless center jumpers to simplify jumpering terminals together
