Allen-Bradley - MINI RELAY 4C/O 10A (24VDC) - 700-HF34Z24
£20.48
/ each
£20.48
1
Delivery
Number of available items for delivery:0
Essential specifications
Type of electric plug connection - Plug-in connection
Complete with socket - no
Rated control supply voltage Us at DC - 24...24 V
Voltage type for actuating - DC
With LED indication - no
Packaging
1 each
GTIN
10662468850411
Supplier Ref
700-HF34Z24
Manufacturer Ref
700-HF34Z24
Commercial Reference
700-HF34Z24
Type of electric plug connection:
Plug-in connection
Complete with socket:
no
Rated control supply voltage Us at DC:
24...24 V
Voltage type for actuating:
DC
With LED indication:
no
Number of contacts as change-over contact:
4
Type of switch contact:
Single contact
Nominal current:
10 A
IP-rating:
IP20
Width:
41.6 mm
Height:
33.5 mm
Depth:
36.1 mm
General Purpose Miniature Square Base Relay, 4PDT, 24V DC
- These small relays—used in industrial applications—are available from
- Rockwell Automation in two- and four-pole versions. Two styles of sockets
- are available, as well.
- Clear cover
- Allows visual inspection of terminals.
- Plug-in terminals
- Secure connections, yet easy to install or remove relays.
- What’s New
- Color coding
- Tabs and coil covers indicate coil voltage type: orange for AC and blue for DC.
- Push-to-test with manual override
- Manual override feature enables changing contact state, even when coils
- are not energized. This upgrade changes all catalog numbers that had the (-1) option to the new (-3) option.
- Increased contact ratings
- Relays are now rated for 12 amps.
- Visual
- Wiring diagram on top faceplate
- Mechanical indicator
- Sockets
- Available in two styles for each contact configuration, one that is compatible
- with Allen-Bradley general purpose relay accessories such as surge suppressors and timing units and the second with traditional open style terminals.
