Essential specifications
Number of poles - 4
Rated current - 40 A
Rated fault current - 0.1 A
Rated voltage - 400 V
Rated impulse withstand voltage Uimp - 4 kV
Packaging
1 each
GTIN
00885630618159
Supplier Ref
1492-RCDA4B40
Manufacturer Ref
1492-RCDA4B40
Commercial Reference
1492-RCDA4B40
Number of poles:
4
Rated current:
40 A
Rated fault current:
0.1 A
Rated voltage:
400 V
Rated impulse withstand voltage Uimp:
4 kV
Mounting method:
DIN rail
Short-circuit breaking capacity (Icw):
10 kA
Frequency:
50/60 Hz
IP-rating:
IP2X
Built-in depth:
67 mm
Ambient temperature during operating:
-25...55 °C
Residual Circuit Breaker. Standard Configuration, 4-pole, 100mA Sensitivity, 40 A, No Delay Option
- Provides protection against current leakage to ground (earth) caused by an insulation
- loss between a live conductor and an exposed conductive part (such as an abraded wire, or a grounded person touching the live conductor)
- Suitable for protection against AC and pulsating DC (rectified AC) earth leakage current
- 30 mA sensitivity devices for personnel protection (consult local requirements)
- 100, 300 and 500 mA sensitivity devices for equipment protection
- Dual terminals allow a more secure connection of two wires, or both a wire and bus bar
- Reversible line and load connections
