Legrand - Dx3 100a Sp Isolating Switch - 406423

Rated permanent current Iu:

100 A

Number of poles:

1

Device construction:

Built-in device fixed built-in technique

Version as main switch:

yes

Version as maintenance-/service switch:

no

Version as safety switch:

yes

Version as emergency stop installation:

no

Max. rated operation voltage Ue AC:

250 V

Conditioned rated short-circuit current Iq:

4500 kA

Motor drive optional:

no

Motor drive integrated:

no

Floor mounting:

no

Suitable for front mounting 4-hole:

no

Suitable for front mounting centre:

no

Suitable for distribution board installation:

yes

Suitable for intermediate mounting:

no

Type of control element:

Toggle

Interlockable:

yes

Connection type main current circuit:

Screw connection

Degree of protection (IP), front side:

IP20
