Merlin Gerin - INTERPACT INS40 3 POLE - 28900

Rated permanent current Iu:

40 A

Number of poles:

3

Device construction:

Built-in device fixed built-in technique

Version as main switch:

yes

Version as maintenance-/service switch:

no

Version as safety switch:

no

Version as emergency stop installation:

no

Max. rated operation voltage Ue AC:

500 V

Conditioned rated short-circuit current Iq:

75 kA

Number of auxiliary contacts as normally closed contact:

0

Number of auxiliary contacts as normally open contact:

0

Number of auxiliary contacts as change-over contact:

0

Motor drive optional:

no

Motor drive integrated:

no

Voltage release optional:

no

Floor mounting:

yes

Suitable for front mounting 4-hole:

no

Suitable for front mounting centre:

no

Suitable for distribution board installation:

yes

Suitable for intermediate mounting:

no

Type of control element:

Short thumb-grip

Interlockable:

no

Connection type main current circuit:

Screw connection

Degree of protection (IP), front side:

IP20
